Staffed by a team of skilled machinists and engineers, our facilities produce precisely machined, finished and semi-finished parts while adhering to close tolerances. These parts include quality down-hole components and completion tools such as mandrels, pup joints, stator tubes, rotors, PBR's, liner hangers, drill collars, crossover bodies, core barrels, and packers.
GLOBAL EQUIPMENT & CAPABILITIES:
ID RANGE | OD RANGE | MAX LENGTH | |
DEEP HOLE BORING | 0.95” - 18.00” | 2.00” - 23.00” | 32 Ft |
GUNDRILLING | 0.50” - 1.500” | 1.00” - 4.25” | 5 Ft |
HONING | 1.50” - 18.00” | 3.00" - 22.00” | 40 Ft |
PULL BORING | 1.50” - 10.50” | 3.00” - 18.00” | 26 Ft |
TURNING | - | 1.00" - 31.50" | 40 Ft |
CNC | 1.50” - 18.00” | 31.50” Max | 30 Ft |
STRAIGHTENING | - | 650 Tons | 34 Ft |
Heat Treatment
Through our custom-built continuous heat treatment line, green bar and tube can be processed and transformed into multiple stress-free precise grades – consistently meeting customers’ exacting specifications. The Continuous Heat Treat (CHT) line is controlled using the latest advances in technology including touch-screen operator interfaces showing real-time technical data. The fully programmable line gives us precise control of temperature, quenching, austenitizing and tempering soak times specific to the product chemistry.
HEAT TREAT MATERIAL CAPABILITIES:
WALL | OD RANGE | LENGTH MAXIMUM | |
TUBING | 0.300" - 2.000" | 5.500" - 14.375" | 45 FT |
SOLID BAR | 0.50” - 1.500” | 4.000" - 8.500" | 45 FT |
